Machine Shop

Mussell Crane Mfg.’s Machine Shop has the equipment needed to serve the most demanding requirements for precision, speed and quality.

In our 8,500 ft2 machine shop, we have more than eleven major machine tools that routinely handle parts up to 32.28 inches in diameter and as small as 3/8 inch.

Our experienced technicians provide computer-aided design, 3-axis CNC milling & tooling (traditional milling & tooling), fabrication, welding, saw cutting & cylindrical grinding.

We also supply quality replacement & repair parts, custom tools, jigs & fixtures, and prototype work.

We cut aluminum, brass, plastic, and even more difficult to machine materials like stainless steel, tool steel, copper, cast iron, and titanium with extreme precision machining within .00025”ø.

CNC Turning

MAZAK SLANT TURN 80N/2000 CNC UNIVERSAL LATHE
Max. Swing 42.13”, Max. Turning Diameter 32.28”, Max. Length 73.8”.

MAZAK NEXUS 200-II TURNING CENTER
Max. Swing 24”, Max. Turning Diameter 13”, Max. Length 24”.

HITACHI SEIKI HT-20SII TURNING CENTER
Max. Swing 15”, Max. Turning Diameter 12”, Max. Length 15”.

CNC Milling

HYUNDAI SPT-V100 VERTICAL MACHING CENTER
Table 16” X 44”, X-Axis Travel 30”, Y-Axis Travel 16”, Z-Axis Travel 25”.

MAZAK VTC-16B CNC VERTICAL MACHING CENTER
Table 16” X 57”, X-Axis Travel 44”, Y-Axis Travel 16”, Z-Axis Travel 20”.

Gear Shaping

FELLOWS GEAR SHAPER 36-6
Pitch Diameter External 40” Max., Pitch Diameter Internal 36”, Face Width 6” Hundreds of Cutters for Gears, Splines, Sprockets and Other Special Tooth Forms.

Gear Hobbing

MODUL GEAR HOBBER ZFWZ400
Helical Spur Wheel Max. 16” Diameter, Worm Wheel Max. 16” Diameter.

Broaching

LAPONTE INTERNAL BROACHING MACHINE
Max. Stroke 48”, Maximum 50-Ton Various Spline Broach Tools & Keyway Broach Tools.

Slotting

SACHMAN TOOLROOM SLOTTER
Max. Stroke 8”, Indexing Table, Custom Internal Keyways to Any Width.

Sawing

MARVEL BANDSAW
Auto In-Feed, Max. 24” Diameter.

Lathe

TOS SN40B CENTER LATHE
Max. 16” Swing Diameter X 40”.

Ironworker

PEDDINGHAUS MECHANICAL IRONWORKER 210A/16
70-Ton Capacity.

Drilling

KAO MING VMR-700DS RADIAL DRILL

Fabricating & Welding

Canadian Welding Bureau (CWB) and American Welding Society (AWS) Certified.

Engineering & Design

Computer Aided Design (CAD) & Drafting, Solid Works 3D Mechanical Design, and GibbsCAM Software.
